WPCS100 Fire Collar - Max Pipe Size 117mm - 1 Hour

WPCS100/1

Intumescent pipe collar to fire seal openings around pipes and cables

Quantity Range

Unit Price

Unit Saving

1 - 24

£7.73

No Saving

25 - 49

£7.34

£0.39

50 - 99

£6.96

£0.77

100 - 199

£6.57

£1.16

200+

£6.18

£1.55

Earn 9 loyalty points, worth £0.18, with this purchase.

Description

Grey metal collar lined with intumescent material which expands in a fire to provide 1 hour fire protection, with a quick-release clip for fitting around a wide variety of metal or plastic pipes and cables.

– Provides up to 1 hour fire protection for pipes from 75mm-200mm in diameter

– Acoustic version offers both airborne and impact sound protection

– Adjustable brackets allow for fitting in hard-to-access areas

FIRE TEST PERFORMANCE

Tested to BS476 Parts 20, 21 & 22 (1987), giving up to 1 hours of fire protection.

Also tested at VNE to European Standard EN1363-1 (2000).

Collar Ref Pipe Size Int Dia Max Pipe Size Ext Dia Ext Collar Dia Depth
WPCS75/1 75mm 87mm 103mm 30mm
WPCS100/1 100mm 117mm 137mm 30mm
WPCS127/1 127mm 137mm 161mm 30mm
WPCS150/1 150mm 167mm 195mm 30mm
WPCS175/1 175mm 187mm 219mm 30mm
WPCS200/1 200mm 212mm 248mm 30mm

Specifications

Brand Envirograf
Weight 0.25kg
